Electric belt hoists adopt high strength composite fiber lifting belt and oil-free lubrication drive system, featuring low noise and minimal particle emission, suitable for material handling applications in high standard cleanroom workshops.
Electric belt hoists are professional lifting equipment designed for high-cleanliness production environments, mainly used in high-end industrial scenarios with stringent requirements for air cleanliness, particle control and operational stability. This lifting system adopts high strength oil-free flexible belt transmission structure and fully enclosed drive system, effectively preventing metal wear particles and lubrication-related contaminants, ensuring compatibility with ISO Class 5 - 8 cleanroom material handling requirements.
Modular Components of Electric Belt Hoists
Drive Motors: Designed with fully enclosed motors to prevent internal dust dispersion and feature low-noise operation.
Composite Fiber Belts: Manufactured from high strength composite fiber materials with high tensile strength, excellent wear resistance and low elongation, producing no metal chip contamination.
Reduction and Brake Systems: Built with high precision gear reduction mechanisms and electromagnetic brake systems to ensure smooth lifting and lowering of loads as well as precise positioning.
Fully Sealed Protective Housings: Made with anti-corrosion coating or stainless steel, providing corrosion resistance, easy cleaning and resistance to dust accumulation.
Intelligent Control Pendents: Support stepless speed regulation and programmable closed-loop fixed-point positioning, equipped with safety interlock switches for long service life.
Product Advantages of Belt Lifting Hoists
The flexible belt transmission combined with fully enclosed drive structure significantly reduces metal dust and lubrication vapor emissions at the source of mechanical friction, meeting strict cleanroom requirements.
The belt transmission system effectively suppresses impact loads and micro-vibrations during lifting and braking, improving stability and safety in precision equipment handling.
Key moving components are made of wear-resistant materials and modular designs, requiring no frequent lubrication. Belt replacement is convenient, significantly reducing downtime and overall maintenance costs.
Integrated safety features such as overload protection, travel limit protection, emergency braking, and power-off self-locking ensure stable and reliable operation under complex working conditions.
The overall design complies with SEMI and ISO 14644 cleanroom standards, making it suitable for high-end manufacturing applications.
Technical Specifications
| Item | Parameter Range |
|---|---|
| Rated Load | 150 kg - 5,000 kg |
| Lifting Height | 3 m - 25 m (customizable) |
| Lifting Speed | 2 - 8 m/min (variable frequency adjustable) |
| Duty Class | M3 - M6 |
| Cleanliness Class | ISO 5 - ISO 8 |
| Sling Material | Kevlar / Polyester composite fiber |
| Power Supply | 380V / 450V |
| Ingress Protection | IP54 - IP65 |
| Noise Level | ≤ 65 dB |
| Control Method | Intelligent pendant controller / Wireless remote control |
| Operating Temperature | -40℃ ~ +100℃ |
Material Handling Solutions for Various High-End Industries
Semiconductor wafer fabrication workshops
Pharmaceutical and biotechnology GMP cleanrooms
Precision electronics and chip packaging production lines
Food processing facilities
High-end laboratories and research institutions
Partner with a Professional Cleanroom Hoists Supplier
KUNFENG cleanroom belt hoists feature light weight, low energy consumption and smooth operation, making them an economical and efficient ideal solution for customers. If you are looking for an electric lifting hoist suitable for cleanroom workshops, contact us now for professional customized solutions and product quotations.
