The overhead fiber rope crane adopts high strength fiber ropes and precision servo control, enabling smooth lifting and millimeter-level positioning, suitable for the hoisting of wafer equipment and precision components in semiconductor workshop.
The overhead fiber rope crane adopts high strength fiber rope hoisting technology with low wear and low dust emission, featuring smooth operation and precise positioning, which can effectively reduce the impact on clean room environments. With compact overall structure, it is suitable for high cleanliness workshops such as Class 100 / Class 1000, and can safely complete the hoisting of wafer manufacturing equipment and precision components. Fiber rope crane also reduces vibration and noise, enhancing the safety and reliability of semiconductor production processes.
Advantages of Overhead Fiber Rope Crane
Effectively prevent particulate contamination of the semiconductor production environment and meet the stringent cleanliness requirements of semiconductor workshops.
The fiber rope features a soft texture, which can avoid scratching or collision damage to the surfaces of precision items such as semiconductor equipment and wafers during hoisting.
Equipped with advanced intelligent control system, it enables precise control of the hoisting process to ensure the stable operation of loads.
Achieve precise lifting, lowering and positioning operations, meeting the high hoisting accuracy requirements of semiconductor production.
Support customized design based on working conditions to meet the operational requirements for different load capacities, spans and lifting heights.
Application of Electric Fiber Rope Hoist in Semiconductor Workshop
Equipment handling and installation: When building or updating equipment in semiconductor workshops, various precision semiconductor manufacturing equipment, such as photolithography machines, etc., need to be handled and installed.
Wafer handling: Fiber rope crane can use specially designed clamps or hoists to accurately grab and lift wafer carriers to ensure the stability and safety of wafers during handling.
Lifting of raw materials and parts: Semiconductor production requires a large amount of raw materials and parts, such as silicon wafers, photoresists and electronic components. Fiber rope hoist can be used to lift these materials from warehouses or storage areas to designated locations on the production line.
Equipment repair and maintenance: When semiconductor equipment fails or requires regular maintenance, it can be used to lift parts of the equipment for repair, replacement or cleaning.
Technical Parameters (Customizable for Different Working Conditions)
| Item | Technical Specification |
|---|---|
| Rated Load | 150 kg - 10,000 kg |
| Span | 3 m - 20 m |
| Lifting Height | 4 m - 12 m |
| Lifting Speed | 0.5 - 10 m/min (variable frequency control) |
| Travel Speed | 5 - 25 m/min |
| Positioning Accuracy | ±1 mm |
| Cleanliness Class | ISO Class 5 - Class 8 |
| Lifting Device | High strength fiber rope hoist |
| Material | Stainless steel / anti-corrosion coated steel |
| Control Method | Push button control / Remote control / PLC automation |
| Protection Class | IP54 - IP65 |
KUNFENG innovative fiber rope cranes have become the ideal lifting equipment for semiconductor workshops, capable of providing efficient and safe material handling solutions while maintaining cleanliness. Click here contact us for a customized design and product quotation that meet your production requirements!
